5502405003F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 5MM HE RED TRI BLOCK
PDF
/
Inventory: 1466
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Published 2002
Series 550
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Red (x 3)
Voltage - Rated 2V
HTS Code 8541.40.20.00
Number of Functions 3
Terminal Pitch 2.54mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -25°C
Configuration 3 Wide
Current 10mA
Viewing Angle 50°
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 7.0 mcd
Millicandela Rating 7mcd
Wavelength - Peak 650nm
Forward Voltage-Max 2.2V
Overall Height 5.96mm
Number of LEDs 3
Luminous Intensity-Min 0.0065 cd
Compliance
RoHS Status ROHS3 Compliant
