MP-2016-1100-40-70
RoHS
RoHS compliant
RoHS compliantPackage 0806 (2016 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED Uni-Color White 26lm 4000K Chip LED 2-Pin SMD T/R
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.127909
≥1 USD $0.127909
≥10 USD $0.120668
≥100 USD $0.113838
≥500 USD $0.107394
≥1000 USD $0.101316
Inventory: 1209
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0806 (2016 Metric)
Number of Pins 2
Thermal Resistance of Package 35°C/W
Technical
Packaging Tape & Reel (TR)
Published 2014
Series MP-2016
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Color White, Neutral
Packing Method TAPE AND REEL
Number of Functions 1
Reach Compliance Code unknown
Case Code (Metric) 2016
Case Code (Imperial) 0806
Configuration SINGLE
Max Current Rating 120mA
Voltage - Forward (Vf) (Typ) 3V
Viewing Angle 110°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 60mA
Lens Style Rectangular
Lumens/Watt @ Current - Test 144 lm/W
CCT (K) 4000K
CRI (Color Rendering Index) 70
Luminous Flux 26 lm
Reverse Voltage 5V
Flux @ 25°C, Current - Test 26lm Typ
Number of LEDs 1
Dimensions
Height Seated (Max) 0.020 0.52mm
Compliance
RoHS Status ROHS3 Compliant
