MXA8-PW30-H001

Lumileds
RoHS
RoHS RoHS compliant
Package 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description Lumileds MXA8-PW30-H001, LUXEON 3535L HE Series White Mid-Power LED, 3000K, 3535, Round Lens SMD package
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.1482
≥1 USD $0.1482
≥10 USD $0.1216
≥100 USD $0.1178
≥500 USD $0.114
≥1000 USD $0.1102
Inventory: 12005
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Height Seated (Max) 0.031 0.80mm

Technical

T-code T-1
Number of LEDs 1
Flux @ 25°C, Current - Test 46lm Typ
Overall Height 0.8mm
Reverse Voltage -5V
Luminous Flux 46 lm
CRI (Color Rendering Index) 80
CCT (K) 3000K
Lumens/Watt @ Current - Test 159 lm/W
Lens Style Circular, Round
Current - Test 100mA
Forward Current 300mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 115°
Voltage - Forward (Vf) (Typ) 2.9V
Max Current Rating 300mA
Configuration SINGLE
Number of Functions 1
Additional Feature UL RECOGNIZED
Color White, Warm
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Discontinued
Size / Dimension 0.138Lx0.134W 3.50mmx3.40mm
Series LUXEON 3535L
Published 2015
Packaging Cut Tape (CT)

Physical

Thermal Resistance of Package 18°C/W
Number of Pins 2
Package / Case 1414 (3535 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver

Supply Chain

Factory Lead Time 6 Weeks
