LXZ2-5070
RoHS
RoHS compliant
RoHS compliantPackage 0806 (2016 Metric)
Category Optoelectronics / LED Lighting - White
Description
LUXEON Z ES High Power SMT LED Emitter 70 CRI 5000K 220 lm Min 700 mA
PDF
/
Buying Options
Total Price: USD $2.16
Unit Price: USD $2.1648
≥1 USD $2.1648
≥10 USD $1.44408
≥100 USD $1.111264
≥500 USD $1.004555
≥1000 USD $0.863289
Inventory: 6125
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0806 (2016 Metric)
Number of Pins 2
Thermal Resistance of Package 3°C/W
Technical
Packaging Tape & Reel (TR)
Published 2014
Series LUXEON Z ES
Size / Dimension 0.080Lx0.065W 2.04mmx1.64mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Max Operating Temperature 135°C
Min Operating Temperature -40°C
Color White, Cool
Additional Feature UL RECOGNIZED
Number of Functions 1
Configuration SINGLE
Max Current Rating 1A
Voltage - Forward (Vf) (Typ) 2.8V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 700mA
Lens Style Rectangular
Lumens/Watt @ Current - Test 125 lm/W
CCT (K) 5000K
CRI (Color Rendering Index) 70
Current - Max 1.2A
Lens Color White
Luminous Flux 215 lm
Flux @ 85°C, Current - Test 245lm Typ
Number of LEDs 1
Dimensions
Height 680μm
Height Seated (Max) 0.031 0.78mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
