L130-4080001400001
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3014 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED LUXEON NEU WHITE 4000K 2SMD
PDF
/
Inventory: 1155
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3014 Metric)
Number of Pins 2
Thermal Resistance of Package 35°C/W
Technical
Packaging Tape & Reel (TR)
Published 2014
Series LUXEON 3014
Size / Dimension 0.118Lx0.055W 3.00mmx1.40mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color White, Neutral
Subcategory Visible LEDs
Max Current Rating 100mA
Voltage - Forward (Vf) (Typ) 3.1V
Viewing Angle 116 °
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 60mA
Lens Style Rectangular
Lumens/Watt @ Current - Test 124 lm/W
CCT (K) 4000K
CRI (Color Rendering Index) 80
Luminous Flux 25 lm
Reverse Voltage -5V
Forward Voltage-Max 3.3V
Overall Height 0.75mm
Flux @ 25°C, Current - Test 23lm Typ
Number of LEDs 1
Dimensions
Height Seated (Max) 0.033 0.83mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
