L130-2790003000W21
RoHS
RoHS compliant
RoHS compliantPackage 1212 (3030 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED LUXEON WARM WHITE 2700K 2SMD
PDF
/
Inventory: 5714
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1212 (3030 Metric)
Thermal Resistance of Package 12°C/W
Technical
Packaging Cut Tape (CT)
Published 2015
Series LUXEON 3030 2D
Size / Dimension 0.118Lx0.118W 3.00mmx3.00mm
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color White, Warm
Max Current Rating 240mA
Voltage - Forward (Vf) (Typ) 6.1V
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 120mA
Lens Style Circular
Lumens/Watt @ Current - Test 109 lm/W
CCT (K) 2700K
CRI (Color Rendering Index) 90
Luminous Flux 80 lm
Reverse Voltage -10V
Flux @ 25°C, Current - Test 80lm Typ
Number of LEDs 1
Dimensions
Height Seated (Max) 0.024 0.62mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
