XTEAWT-E0-0000-000000HE3
RoHS
RoHS compliant
RoHS compliantPackage 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description
XLamp? XT-E 5000K White Cool Surface Mount LED Lighting series 2.77V 1.5A 5C/W 115°
PDF
/
Inventory: 1633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 1414 (3535 Metric)
Thermal Resistance of Package 5°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? XT-E
Size / Dimension 0.136Lx0.136W 3.45mmx3.45mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color White, Cool
HTS Code 8541.40.20.00
Voltage - Forward (Vf) (Typ) 2.77V
Viewing Angle 115°
Current - Test 350mA
Lumens/Watt @ Current - Test 149 lm/W
CCT (K) 5000K
Current - Max 1.5A
Flux @ 85°C, Current - Test 144lm 139lm~148lm
Dimensions
Height Seated (Max) 0.100 2.54mm
Compliance
RoHS Status RoHS Compliant
