XRCWHT-L1-0000-00A09
RoHS
RoHS compliant
RoHS compliantPackage 3529 (9073 Metric)
Category Optoelectronics / LED Lighting - White
Description
High Power LEDs - White White 87.4lm XLamp XR-C LED
PDF
/
Inventory: 8487
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 3529 (9073 Metric)
Thermal Resistance of Package 12°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? XR-C
Size / Dimension 0.354Lx0.276W 9.00mmx7.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Color White
Base Part Number XRC
Max Current Rating 500mA
Voltage - Forward (Vf) (Typ) 3.5V
Viewing Angle 90°
Forward Current 350mA
Lumens/Watt @ Current - Test 74 lm/W
Luminous Flux 87.4 lm
Flux @ 25°C, Current - Test 91lm 87lm~94lm
Color Rendering Index (CRI) 75
Dimensions
Height 4.4mm
Height Seated (Max) 0.181 4.60mm
Compliance
RoHS Status RoHS Compliant
