XPGBWT-U1-0000-009E7
RoHS
RoHS compliant
RoHS compliantPackage 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description
High Power LEDs - White White, 80.6lm
PDF
/
Inventory: 9860
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.094 2.39mm
Height 2.36mm
Technical
Flux @ 85°C, Current - Test 84lm 81lm~87lm
Reverse Voltage 5V
Luminous Flux 80.6 lm
Illumination Color White
CRI (Color Rendering Index) 90
CCT (K) 3000K
Lumens/Watt @ Current - Test 83 lm/W
Forward Current 350mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 125°
Voltage - Forward (Vf) (Typ) 2.9V
Max Current Rating 1.5A
Number of Elements 1
Base Part Number XPGBWT
Depth 3.45mm
Subcategory Visible LEDs
Color White, Warm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.136Lx0.136W 3.45mmx3.45mm
Series XLamp? XP-G2
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 4°C/W
Number of Pins 2
Package / Case 1414 (3535 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
