XPGBWT-L1-0000-00FF4
RoHS
RoHS compliant
RoHS compliantPackage 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description
High Power LEDs - White White, 122lm
PDF
/
Inventory: 8506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.094 2.39mm
Height 2.36mm
Technical
Flux @ 85°C, Current - Test 126lm 122lm~130lm
Luminous Flux 122 lm
Illumination Color White
CRI (Color Rendering Index) 75 (Typ)
CCT (K) 4750K
Lumens/Watt @ Current - Test 124 lm/W
Forward Current 350mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 125°
Voltage - Forward (Vf) (Typ) 2.9V
Max Current Rating 1.5A
Base Part Number XPGBWT
Color White, Neutral
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.136Lx0.136W 3.45mmx3.45mm
Series XLamp? XP-G2
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 4°C/W
Number of Pins 2
Package / Case 1414 (3535 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
