XPGBWT-01-0000-00JC3
RoHS
RoHS compliant
RoHS compliantPackage 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description
XLamp? XP-G2 4300K 70 (Typ) White Neutral LED Lighting series 3.45mm 3.8V 1.5A 4C/W
PDF
/
Inventory: 4003
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1414 (3535 Metric)
Thermal Resistance of Package 4°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? XP-G2
Size / Dimension 0.136Lx0.136W 3.45mmx3.45mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color White, Neutral
Max Current Rating 1.5A
Voltage - Forward (Vf) (Typ) 3.8V
Viewing Angle 115°
Current - Test 350mA
Lumens/Watt @ Current - Test 114 lm/W
CCT (K) 4300K
CRI (Color Rendering Index) 70 (Typ)
Forward Voltage 3.8V
Current - Max 1.5A
Flux @ 85°C, Current - Test 152lm 148lm~156lm
Dimensions
Height Seated (Max) 0.094 2.39mm
Length 3.45mm
Width 3.45mm
Compliance
RoHS Status RoHS Compliant
