XPCWHT-L1-0000-00A01
RoHS
RoHS compliant
RoHS compliantPackage 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED Uni-Color White 2-Pin SMD T/R
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.836
≥100 USD $0.81224
≥500 USD $0.748
≥1000 USD $0.68024
≥3000 USD $0.63712
Inventory: 6934
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.084 2.13mm
Height 2mm
Technical
Flux @ 25°C, Current - Test 91lm 87lm~94lm
Forward Voltage-Max 3.9V
Reverse Voltage 5V
Luminous Flux 87.4 lm
Lens Color Clear
Illumination Color White
CRI (Color Rendering Index) 70 (Typ)
CCT (K) 5000K ~ 10000K
Lumens/Watt @ Current - Test 81 lm/W
Lens Style Diffused, Dome, Square
Current - Test 350mA
Forward Current 500mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 115°
Voltage - Forward (Vf) (Typ) 3.2V
Max Current Rating 500mA
Configuration SINGLE
Number of Elements 1
Base Part Number XPC
Depth 3.45mm
Number of Functions 1
Packing Method TR, 7 INCH
Additional Feature UL RECOGNIZED
Color White, Cool
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.136Lx0.136W 3.45mmx3.45mm
Series XLamp? XP-C
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 12°C/W
Shape ROUND
Number of Pins 2
Package / Case 1414 (3535 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
