XMLBWT-02-0000-000LT50E8
RoHS
RoHS compliant
RoHS compliantPackage 2020 (5050 Metric)
Category Optoelectronics / LED Lighting - White
Description
XLamp? XM-L2Gen 2 2700K 80 (Typ) White Warm LED Lighting series 2.85V 700mA 2.5C/W 125°
PDF
/
Inventory: 2622
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.124 3.15mm
Technical
Flux @ 85°C, Current - Test 270lm 260lm~280lm
CRI (Color Rendering Index) 80 (Typ)
CCT (K) 2700K
Lumens/Watt @ Current - Test 135 lm/W
Current - Test 700mA
Viewing Angle 125°
Voltage - Forward (Vf) (Typ) 2.85V
Max Current Rating 3A
Color White, Warm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.197Lx0.197W 5.00mmx5.00mm
Series XLamp? XM-L2 Gen 2
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 2.5°C/W
Package / Case 2020 (5050 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
