XMLBWT-02-0000-000HT20E8
RoHS
RoHS compliant
RoHS compliantPackage 2020 (5050 Metric)
Category Optoelectronics / LED Lighting - White
Description
XLamp? XM-L2 Round 2700K XMLBWT LED Lighting series 2.85V 700mA 2.5C/W 125°
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.842159
≥1 USD $2.842159
≥10 USD $2.68128
≥100 USD $2.529507
≥500 USD $2.38633
≥1000 USD $2.251258
Inventory: 7074
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.124 3.15mm
Height 3.02mm
Technical
Number of LEDs 1
Flux @ 85°C, Current - Test 210lm 200lm~220lm
Luminous Flux 200 lm
Lens Color Clear
Illumination Color White
CRI (Color Rendering Index) 80
CCT (K) 2700K
Lumens/Watt @ Current - Test 105 lm/W
Lens Style Round
Forward Current 700mA
Viewing Angle 125°
Voltage - Forward (Vf) (Typ) 2.85V
Max Current Rating 3A
Base Part Number XMLBWT
Color White, Warm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.197Lx0.197W 5.00mmx5.00mm
Series XLamp? XM-L2
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 2.5°C/W
Number of Pins 2
Package / Case 2020 (5050 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
