XMLBWT-00-0000-000LU20F4
RoHS
RoHS compliant
RoHS compliantPackage 2020 (5050 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED XLAMP NEUTRAL WHT 4750K SMD
PDF
/
Inventory: 2275
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2020 (5050 Metric)
Thermal Resistance of Package 2.5°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? XM-L2 Gen 2
Size / Dimension 0.197Lx0.197W 5.00mmx5.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color White, Neutral
HTS Code 8541.40.20.00
Max Current Rating 3A
Voltage - Forward (Vf) (Typ) 2.85V
Viewing Angle 125°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 700mA
Lumens/Watt @ Current - Test 155 lm/W
CCT (K) 4750K
CRI (Color Rendering Index) 75 (Typ)
Flux @ 85°C, Current - Test 310lm 300lm~320lm
Dimensions
Height Seated (Max) 0.124 3.15mm
Compliance
RoHS Status RoHS Compliant
