XMLBEZ-00-0000-0B0HV340F
RoHS
RoHS compliant
RoHS compliantPackage 2020 (5050 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED EASYWHT NEU WHT 4000K 2SMD
PDF
/
Inventory: 9984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.124 3.15mm
Technical
Flux @ 85°C, Current - Test 430lm 420lm~440lm
CRI (Color Rendering Index) 80
CCT (K) 4000K 4-Step MacAdam Ellipse
Lumens/Watt @ Current - Test 102 lm/W
Current - Test 700mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 115°
Voltage - Forward (Vf) (Typ) 6V
Max Current Rating 2A
HTS Code 8541.40.20.00
Color White, Neutral
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.197Lx0.197W 5.00mmx5.00mm
Series Easywhite?, Xlamp? XM-L2
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 2.5°C/W
Package / Case 2020 (5050 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
