MLESWT-A1-0000-0002F7
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, J-Lead Exposed Pad
Category Optoelectronics / LED Lighting - White
Description
LED XLAMP WARM WHITE 3250K 4SMD
PDF
/
Inventory: 7009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, J-Lead Exposed Pad
Number of Pins 4
Thermal Resistance of Package 11°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? ML-E
Size / Dimension 0.138Lx0.124W 3.50mmx3.15mm
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Color White, Warm
Subcategory Visible LEDs
Base Part Number MLESWT
Max Current Rating 167mA
Voltage - Forward (Vf) (Typ) 9.6V
Viewing Angle 120°
Forward Current 50mA
Lumens/Watt @ Current - Test 90 lm/W
CCT (K) 3250K (3000K ~ 3500K)
CRI (Color Rendering Index) 80
Illumination Color White
Luminous Flux 39.8 lm
Forward Voltage-Max 10.2V
Flux @ 25°C, Current - Test 43lm 40lm~46lm
Flux @ 85°C, Current - Test 39lm
Reverse Voltage-Max 5V
Luminous Intensity-Min 120 cd
Dimensions
Height 1.2mm
Height Seated (Max) 0.052 1.33mm
Compliance
RoHS Status RoHS Compliant
