MLCSWT-U1-0000-000WE5
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, J-Lead Exposed Pad
Category Optoelectronics / LED Lighting - White
Description
XLamp? ML-C 4000K MLCSWT 90 LED Lighting series 7V 50mA 25lm 24lm~27lm 120°
PDF
/
Inventory: 2943
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, J-Lead Exposed Pad
Number of Pins 4
Thermal Resistance of Package 13°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? ML-C
Size / Dimension 0.138Lx0.124W 3.50mmx3.15mm
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Color White, Neutral
Subcategory Visible LEDs
Depth 3.15mm
Base Part Number MLCSWT
Number of Elements 1
Max Current Rating 175mA
Voltage - Forward (Vf) (Typ) 6.4V
Viewing Angle 120°
Forward Current 50mA
Lumens/Watt @ Current - Test 78 lm/W
CCT (K) 4000K
CRI (Color Rendering Index) 90
Illumination Color White
Luminous Flux 23.5 lm
Forward Voltage-Max 7V
Flux @ 25°C, Current - Test 25lm 24lm~27lm
Reverse Voltage-Max 5V
Dimensions
Height 1.2mm
Height Seated (Max) 0.052 1.33mm
Compliance
RoHS Status RoHS Compliant
