MCE4WT-A2-0000-000MA2
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, Gull Wing Exposed Pad
Category Optoelectronics / LED Lighting - White
Description
LED XLAMP NEUTRAL WHT 4750K 8SMD
PDF
/
Inventory: 3914
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing Exposed Pad
Thermal Resistance of Package 3°C/W
Technical
Packaging Tape & Reel (TR)
Series XLamp? MC-E
Size / Dimension 0.276Lx0.295W 7.00mmx7.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Color White, Neutral
Base Part Number MCE4WT
Max Current Rating 700mA
Voltage - Forward (Vf) (Typ) 3.1V
Viewing Angle 110°
Forward Current 350mA
Current - Test 4 x 350mA
Lumens/Watt @ Current - Test 106 lm/W
CCT (K) 4750K
Current - Max 4 x 700mA
Illumination Color White
Luminous Flux 430 lm
Flux @ 25°C, Current - Test 460lm 430lm~490lm
Color Rendering Index (CRI) 75
Dimensions
Height 4.5mm
Height Seated (Max) 0.181 4.60mm
Compliance
RoHS Status RoHS Compliant
