ASMT-UWBG-ZACP8

Broadcom Limited
RoHS
/
Package 4-SMD, J-Lead Exposed Pad
Category Optoelectronics / LED Lighting - White
Description LED AMST-UWBG NEU WHT SMD
PDF
/
Inventory: 1720
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, J-Lead Exposed Pad
Supplier Device Package 4-PLCC
Thermal Resistance of Package 50°C/W

Technical

Packaging Tape & Reel (TR)
Published 2012
Series AMST-UWBG
Size / Dimension 0.138Lx0.126W 3.50mmx3.20mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Color White, Neutral
Max Current Rating 100mA
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 120°
Current - Test 80mA
Lumens/Watt @ Current - Test 105 lm/W
CCT (K) 4250K (4000K ~ 4500K)
CRI (Color Rendering Index) 85 (Typ)
Forward Voltage 3.2V
Current - Max 100mA
Flux @ 25°C, Current - Test 27lm 18lm~35lm

Dimensions

Height Seated (Max) 0.043 1.10mm

Compliance

RoHS Status RoHS Compliant
