OVSPRBCR4 image
Favorite
RoHS
/
Package 2424 (6060 Metric)
Category Optoelectronics / LED Lighting - Color
Description LED 625NM RED 1W SMD 6 X 6
PDF
/
Inventory: 1512
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 6mm
Length 7mm
Height Seated (Max) 0.059 1.50mm

Technical

Dominant Wavelength 625 nm
Wavelength 625nm 620nm ~ 630nm
Reverse Voltage 12V
Luminous Flux 42 lm
Lens Color Clear
Flux @ Current/Temperature - Test 44lm 33lm~54lm
Temperature - Test 25°C
Illumination Color Red
Current - Max 400mA
Luminous Intensity 26 mcd
Forward Voltage 2.5V
Lumens/Watt @ Current - Test 44 lm/W
Peak Pulse Current 500mA
Lens Style Colorless, Diffused
Current - Test 400mA
Forward Current 400mA
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.5V
Power Dissipation 1.2W
Nominal Supply Current 400mA
Max Current Rating 400mA
Number of Elements 1
Depth 6mm
Max Power Dissipation 1.2W
Voltage - Rated DC 2.5V
Power Rating 1W
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Size / Dimension 0.236Lx0.236W 6.00mmx6.00mm
Published 2008
Packaging Tape & Reel (TR)

Physical

Thermal Resistance of Package 20°C/W
Supplier Device Package SMD
Number of Pins 2
Package / Case 2424 (6060 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
