OVSPBCCR8 image
Favorite
RoHS
/
Package 2828 (7070 Metric)
Category Optoelectronics / LED Lighting - Color
Description LED 470NM BLUE PWR SMD 7 X 7
PDF
/
Inventory: 7266
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Height Seated (Max) 0.146 3.70mm

Technical

Wavelength 470nm 464nm ~ 476nm
Luminous Flux 11 lm
Flux @ Current/Temperature - Test 11lm Typ
Temperature - Test 25°C
Illumination Color Blue
Current - Max 500mA
Forward Voltage 3.6V
Lumens/Watt @ Current - Test 10 lm/W
Current - Test 300mA
Forward Current 300mA
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.6V
Nominal Supply Current 300mA
Max Current Rating 300mA
Power Rating 1W
Color Blue
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Part Status Obsolete
Size / Dimension 0.276Lx0.276W 7.00mmx7.00mm
Published 2005
Packaging Tape & Reel (TR)

Physical

Thermal Resistance of Package 15°C/W
Supplier Device Package SMD
Number of Pins 3
Package / Case 2828 (7070 Metric)
Mounting Type Surface Mount
Mount Surface Mount
