LTPL-P011R
RoHS
/
Package 2-SMD, Gull Wing Exposed Pad
Category Optoelectronics / LED Lighting - Color
Description
LED 1 WATT RED SMD
PDF
/
Inventory: 7215
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, Gull Wing Exposed Pad
Supplier Device Package SMD
Thermal Resistance of Package 5°C/W
Technical
Packaging Tape & Reel (TR)
Published 2008
Series LTPL
Size / Dimension 0.315Dia 8.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Color Red
Power Rating 1W
Max Current Rating 1A
Viewing Angle 120°
Forward Current 350mA
Current - Test 350mA
Forward Voltage 2.3V
Current - Max 1A
Illumination Color Red
Flux @ Current/Temperature - Test 37lm Typ
Lens Color Clear
Luminous Flux 38 lm
Wavelength 625 nm
Dimensions
Height Seated (Max) 0.220 5.60mm
Compliance
RoHS Status RoHS Compliant
Alternative Model
