AA3529SYS/L

Kingbright
RoHS
RoHS RoHS compliant
Package 2-PLCC
Category Optoelectronics / LED Lighting - Color
Description LED 3.5X2.8MM YLW CLR 0.5W SMD
PDF
/
Inventory: 8402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.061 1.55mm

Technical

Overall Height 1.3mm
Wavelength 590nm Typ
Luminous Flux 6 lm
Lens Color Clear
Flux @ Current/Temperature - Test 6lm Typ
Temperature - Test 25°C
Luminous Intensity 3 cd
Lumens/Watt @ Current - Test 11 lm/W
Forward Current 150mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 3.6V
Max Current Rating 150mA
Configuration SINGLE
Number of Functions 1
Packing Method TAPE AND REEL
Power Rating 500mW
HTS Code 8541.40.20.00
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Pbfree Code yes
Size / Dimension 0.126Lx0.110W 3.20mmx2.80mm
Series AA3529
Published 2008
Packaging Tape & Reel (TR)

Physical

Thermal Resistance of Package 90°C/W
Shape ROUND
Package / Case 2-PLCC
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
