ELSH-F41O1-0LPNM-AR3R4
RoHS
RoHS compliant
RoHS compliantPackage 1218 (3246 Metric)
Category Optoelectronics / LED Lighting - Color
Description
LED SHUEN 1W HI POWER ORN SMD
PDF
/
Buying Options
Total Price: USD $3.7
Unit Price: USD $3.703691
≥1 USD $3.703691
≥200 USD $1.478325
≥400 USD $1.428435
≥800 USD $1.404803
Inventory: 3162
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1218 (3246 Metric)
Number of Pins 3
Shape ROUND
Thermal Resistance of Package 12°C/W
Technical
Packaging Tape & Reel (TR)
Published 2011
Series SHUEN
Size / Dimension 0.120Lx0.177W 3.05mmx4.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Orange
Power Rating 1W
Packing Method TAPE AND REEL 7"
Number of Functions 1
Configuration SINGLE WITH BUILT-IN ZENER DIODE
Max Current Rating 400mA
Voltage - Forward (Vf) (Typ) 2.35V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 350mA
Lens Style Circular, Dome
Lumens/Watt @ Current - Test 60 lm/W
Current - Max 600mA
Temperature - Test 25°C
Flux @ Current/Temperature - Test 49lm 45lm~52lm
Luminous Flux 45 lm
Wavelength 615nm 610nm ~ 620nm
Number of LEDs 1
T-code T-1
Dimensions
Height Seated (Max) 0.085 2.15mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
