ELSH-E81B3-0LPNM-DB6B8

Everlight Electronics Co Ltd
RoHS
RoHS RoHS compliant
Package 1218 (3246 Metric)
Category Optoelectronics / LED Lighting - Color
Description LED SHUEN 3W HI POWER BLUE SMD
PDF
/
Inventory: 3250
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1218 (3246 Metric)
Number of Pins 3
Shape ROUND
Thermal Resistance of Package 6°C/W

Technical

Packaging Tape & Reel (TR)
Published 2011
Series SHUEN
Size / Dimension 0.120Lx0.177W 3.05mmx4.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Blue
Power Rating 3W
Packing Method TAPE AND REEL 7"
Number of Functions 1
Configuration SINGLE WITH BUILT-IN ZENER DIODE
Max Current Rating 750mA
Voltage - Forward (Vf) (Typ) 3.55V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 700mA
Lens Style Circular
Lumens/Watt @ Current - Test 9 lm/W
Temperature - Test 25°C
Flux @ Current/Temperature - Test 22lm 20lm~23lm
Lens Color Clear
Luminous Flux 20 lm
Wavelength 463nm 455nm ~ 470nm
Number of LEDs 1

Dimensions

Height Seated (Max) 0.085 2.15mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
