ASMT-QRBD-AEF0E
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Lighting - Color
Description
LED, PLCC4, 0.5W, RED, 16.5LM
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9405
≥1 USD $0.9405
≥10 USD $0.7714
≥100 USD $0.74765
≥500 USD $0.72295
≥1000 USD $0.6992
Inventory: 120808
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Plating Silver
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-PLCC
Number of Pins 4
Thermal Resistance of Package 60°C/W
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 0.126Lx0.110W 3.20mmx2.80mm
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 4
ECCN Code EAR99
Max Operating Temperature 120°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
Subcategory Visible LEDs
Power Rating 500mW
Packing Method TAPE AND REEL 7"
Max Power Dissipation 450mW
Number of Functions 1
Depth 3.2mm
Base Part Number ASMT-Q*BD
Number of Elements 1
Configuration SINGLE
Max Current Rating 150mA
Power Dissipation 450mW
Voltage - Forward (Vf) (Typ) 2.5V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 150mA
Lens Style Circular, Round
Lumens/Watt @ Current - Test 43 lm/W
Luminous Intensity 2.5 cd
Current - Max 300mA
Wavelength - Peak 629.7 nm
Temperature - Test 25°C
Flux @ Current/Temperature - Test 16lm 12lm~20lm
Lens Color Clear
Luminous Flux 16.5 lm
Reverse Voltage 5V
Dominant Wavelength 621.1 nm
Dimensions
Height Seated (Max) 0.083 2.10mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
