ASMT-QGBE-NFH0E
RoHS
/
Package 4-PLCC
Category Optoelectronics / LED Lighting - Color
Description
BROADCOM LIMITED ASMT-QGBE-NFH0E High Brightness LED, PLCC4 Series, Green, 120 , 23 lm, 300 mA
PDF
/
Buying Options
Total Price: USD $40.34
Unit Price: USD $40.34365
≥1 USD $40.34365
≥10 USD $33.10275
≥100 USD $32.0682
≥500 USD $31.03365
≥1000 USD $29.9991
Inventory: 2210
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Silver
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-PLCC
Number of Pins 4
Thermal Resistance of Package 40°C/W
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 0.126Lx0.110W 3.20mmx2.80mm
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 4
ECCN Code EAR99
Max Operating Temperature 110°C
Min Operating Temperature -40°C
Color Green
Additional Feature HIGH RELIABILITY
Subcategory Visible LEDs
Power Rating 500mW
Packing Method TAPE AND REEL 7"
Max Power Dissipation 513mW
Number of Functions 1
Depth 3.2mm
Base Part Number ASMT-Q*BE
Number of Elements 1
Configuration SINGLE
Max Current Rating 150mA
Power Dissipation 513mW
Voltage - Forward (Vf) (Typ) 3.6V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 150mA
Lens Style Circular, Round
Lumens/Watt @ Current - Test 44 lm/W
Luminous Intensity 2.75 cd
Current - Max 300mA
Temperature - Test 25°C
Flux @ Current/Temperature - Test 24lm 15lm~33lm
Luminous Flux 23 lm
Reverse Voltage -4V
Wavelength 522nm Typ
Dominant Wavelength 522 nm
Dimensions
Height Seated (Max) 0.083 2.10mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
