ASMT-AR30-ARR00
RoHS
/
Package 2-SMD, Gull Wing Exposed Pad
Category Optoelectronics / LED Lighting - Color
Description
BROADCOM LIMITED ASMT-AR30-ARR00 LED, Red, SMD, 700 mA, 2.1 V, 625 nm
PDF
/
Inventory: 2676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, Gull Wing Exposed Pad
Number of Pins 2
Thermal Resistance of Package 10°C/W
Technical
Packaging Tube
Published 2010
Size / Dimension 0.315Dia 8.00mm
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Silver (Ag)
Max Operating Temperature 115°C
Min Operating Temperature -40°C
Color Red
Power Rating 3W
Max Power Dissipation 2.45W
Number of Functions 1
Base Part Number ASMT-AR30
Configuration SINGLE
Max Current Rating 700mA
Power Dissipation 2.45W
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 140°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 700mA
Current - Test 350mA
Lens Style Round
Lumens/Watt @ Current - Test 95 lm/W
Wavelength - Peak 635 nm
Temperature - Test 25°C
Flux @ Current/Temperature - Test 70lm 52lm~87lm
Luminous Flux 43 lm
Overall Height 4.1mm
Dimensions
Height Seated (Max) 0.165 4.20mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
