ASMC-QAB2-TAC0E
RoHS
/
Package 4-PLCC
Category Optoelectronics / LED Lighting - Color
Description
AVAGO TECHNOLOGIES ASMC-QAB2-TAC0E High Brightness LED, Envisium, Envisium Series, 593.5 nm, Amber, 6.5 cd, 6.6 lm, 150 mA
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.27715
≥1 USD $2.27715
≥10 USD $1.86865
≥100 USD $1.80975
≥500 USD $1.7518
≥1000 USD $1.6929
Inventory: 2375
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-PLCC
Number of Pins 4
Shape ROUND
Thermal Resistance of Package 60°C/W
Technical
Packaging Tape & Reel (TR)
Published 2009
Series Envisium?
Size / Dimension 0.126Lx0.110W 3.20mmx2.80mm
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Silver (Ag)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Amber
Additional Feature HIGH RELIABILITY
Power Rating 500mW
Packing Method TAPE AND REEL 7"
Number of Functions 1
Overall Height 1.9mm
Wavelength 591nm 583nm ~ 598nm
Luminous Flux 6.6 lm
Lens Color Clear
Flux @ Current/Temperature - Test 7lm 4lm~9lm
Temperature - Test 25°C
Illumination Color Orange
Luminous Intensity 470 mcd
Lumens/Watt @ Current - Test 18 lm/W
Forward Current 150mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.64V
Power Dissipation 470mW
Max Current Rating 300mA
Configuration SINGLE
Base Part Number ASMC-Q*B2
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height Seated (Max) 0.083 2.10mm
