RoHS
/
Package /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description LED PCBA, FINGER BOARD, 3500K
PDF
/
Inventory: 3024
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Technical

Packaging Box
Published 2015
Series Fingerboard
Size / Dimension 259.08mm Lx259.08mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type LED Module
Color White, Warm
Configuration Square
Voltage - Forward (Vf) (Typ) 22.5V
Viewing Angle 120°
Current - Test 700mA
Lens Style Flat
Lumens/Watt @ Current - Test 141 lm/W
CCT (K) 3500K
CRI (Color Rendering Index) 83 (Typ)
Forward Voltage 22.5V
Lens Type Flat
Temperature - Test 25°C
Flux @ Current/Temperature - Test 2215lm Typ

Dimensions

Height 2.08mm
Length 259.08mm
Width 259.08mm

Compliance

RoHS Status RoHS Compliant
