SPHWHAHDNF28YZV3D2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
LED COB D 3000K SQUARE
PDF
/
Buying Options
Total Price: USD $5.77
Unit Price: USD $5.766257
≥1 USD $5.766257
≥200 USD $2.301514
≥500 USD $2.224053
≥1000 USD $2.185979
Inventory: 7402
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Technical
Packaging Tray
Series COB D Gen2
Size / Dimension 19.00mm Lx19.00mm W
Part Status Active
Type Chip On Board (COB)
Color White, Warm
Reach Compliance Code compliant
Configuration Square
Voltage - Forward (Vf) (Typ) 34.6V
Viewing Angle 115°
Current - Test 540mA
Lumens/Watt @ Current - Test 106 lm/W
CCT (K) 3000K 3-Step MacAdam Ellipse
CRI (Color Rendering Index) 95 (Typ)
Current - Max 1.38A
Lens Type Flat
Temperature - Test 85°C
Flux @ Current/Temperature - Test 1976lm Typ
Light Emitting Surface (LES) 14.50mm Dia
Dimensions
Height 1.50mm
Compliance
RoHS Status RoHS Compliant
Alternative Model
