SPHWHAHDNE25YZP3D3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
LED COB D 6500K SQUARE
PDF
/
Buying Options
Total Price: USD $5.24
Unit Price: USD $5.241097
≥1 USD $5.241097
≥200 USD $2.09145
≥500 USD $2.021866
≥1000 USD $1.986418
Inventory: 1601
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Technical
Packaging Tray
Series COB D Gen3
Size / Dimension 19.00mm Lx19.00mm W
Part Status Active
Type Chip On Board (COB)
Color White, Cool
Reach Compliance Code compliant
Configuration Square
Voltage - Forward (Vf) (Typ) 34V
Viewing Angle 115°
Current - Test 450mA
Lumens/Watt @ Current - Test 171 lm/W
CCT (K) 6500K 3-Step MacAdam Ellipse
CRI (Color Rendering Index) 80
Current - Max 1.15A
Lens Type Flat
Temperature - Test 85°C
Flux @ Current/Temperature - Test 2622lm Typ
Light Emitting Surface (LES) 14.50mm Dia
Dimensions
Height 1.50mm
Compliance
RoHS Status RoHS Compliant
