CSM-360-W30M-D22-GT701
RoHS
/
Package Module
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
LED Lighting Modules White 3000K 2500lm @ 3.15A
PDF
/
Inventory: 2861
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Module
Technical
Published 2012
Series CSM-360
Size / Dimension 36.00mm Lx51.00mm W
Feature With Connector
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type LED Module
Color White, Warm
Configuration Rectangle
Max Current Rating 6.3A
Voltage - Forward (Vf) (Typ) 13.14V
Viewing Angle 115°
Forward Current 3.15A
Current - Test 3.15A
Lens Style Circular, Domed
Lumens/Watt @ Current - Test 56 lm/W
CCT (K) 3000K
CRI (Color Rendering Index) 83 (Typ)
Forward Voltage 13.14V
Current - Max 6.3A
Lens Type Domed
Illumination Color White
Temperature - Test 40°C
Flux @ Current/Temperature - Test 2300lm 2100lm~2500lm
Luminous Flux 2.5 klm
Light Emitting Surface (LES) 16.00mm Dia
Number of LEDs 4
Dimensions
Height 5.61mm
Length 36mm
Width 36mm
Compliance
RoHS Status RoHS Compliant
