L2C3-2290107E06000
RoHS
/
Package /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
LED COB COMPACT WARM WHT RECT
PDF
/
Inventory: 6519
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Number of Pins 2
Technical
Packaging Tube
Published 2015
Series LUXEON CoB Compact
Size / Dimension 12.00mm Lx15.00mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Chip On Board (COB)
Color White, Warm
Reach Compliance Code unknown
Configuration Rectangle
Max Current Rating 300mA
Voltage - Forward (Vf) (Typ) 35.5V
Viewing Angle 115°
Forward Current 300mA
Current - Test 200mA
Lens Style Flat, Round
Lumens/Watt @ Current - Test 70 lm/W
CCT (K) 2200K 3-Step MacAdam Ellipse
CRI (Color Rendering Index) 90
Lens Type Flat
Temperature - Test 85°C
Flux @ Current/Temperature - Test 500lm Typ
Luminous Flux 500 lm
Light Emitting Surface (LES) 6.50mm Dia
Number of LEDs 1
Dimensions
Height 1.50mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
