L2C2-30901205E1300

Lumileds
RoHS
RoHS RoHS compliant
Package /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description LED COB 1205 3000K WW 90CRI SMD
PDF
/
Inventory: 6811
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Height 1.50mm

Technical

Number of LEDs 1
Light Emitting Surface (LES) 13.00mm Dia
Luminous Flux 2.322 klm
Flux @ Current/Temperature - Test 2322lm Typ
Temperature - Test 85°C
Lens Type Flat
CRI (Color Rendering Index) 90
CCT (K) 3000K 3-Step MacAdam Ellipse
Lumens/Watt @ Current - Test 111 lm/W
Lens Style Circular, Flat
Current - Test 600mA
Forward Current 1.2A
Viewing Angle 115°
Voltage - Forward (Vf) (Typ) 35V
Max Current Rating 1.2A
Configuration Rectangle
Color White, Warm
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Type Chip On Board (COB)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 20.00mm Lx24.00mm W
Series LUXEON CoB Core Range
Published 2015
Packaging Tube

Physical

Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
