CXA1510-0000-000N0UG40E3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
LED COB CX1510 5000K WHITE SMD
PDF
/
Inventory: 5361
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Technical
Packaging Tray
Series Xlamp? CXA1510
Size / Dimension 15.85mm Lx15.85mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Chip On Board (COB)
Color White, Cool
HTS Code 8541.40.20.00
Configuration Square
Max Current Rating 450mA
Voltage - Forward (Vf) (Typ) 36V
Viewing Angle 115°
Current - Test 250mA
Lumens/Watt @ Current - Test 97 lm/W
CCT (K) 5000K
CRI (Color Rendering Index) 90
Lens Type Flat
Temperature - Test 85°C
Flux @ Current/Temperature - Test 870lm 840lm~900lm
Light Emitting Surface (LES) 8.90mm Dia
Dimensions
Height 1.70mm
Compliance
RoHS Status RoHS Compliant
