CLU048-1212C4-503M2K1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
COB LED 5000K 80CRI
PDF
/
Buying Options
Total Price: USD $58.22
Unit Price: USD $58.219238
≥1 USD $58.219238
≥210 USD $23.230453
≥510 USD $22.453216
≥990 USD $22.069849
Inventory: 5340
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Technical
Packaging Tray
Published 2015
Series CLU048
Size / Dimension 28.00mm Lx28.00mm W
Part Status Active
Type Chip On Board (COB)
Color White, Cool
Configuration Square
Max Current Rating 2.76A
Voltage - Forward (Vf) (Typ) 34.6V
Viewing Angle 120 °
Current - Test 1.08A
Lens Style Flat
Lumens/Watt @ Current - Test 156 lm/W
CCT (K) 5000K 3-Step MacAdam Ellipse
CRI (Color Rendering Index) 80
Forward Voltage 34.6V
Current - Max 2.76A
Lens Type Flat
Temperature - Test 85°C
Flux @ Current/Temperature - Test 5815lm Typ
Light Emitting Surface (LES) 22.00mm Dia
Dimensions
Height 1.40mm
Length 28mm
Width 28mm
Compliance
RoHS Status RoHS Compliant
