BXRC-17E4000-D-74-SE
RoHS
/
Package /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
VERO SE 18D WARM WHITE LED ARRAY
PDF
/
Inventory: 950
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Technical
Published 2016
Series Vero? SE 18 Array
Size / Dimension 36.20mm Dia
Part Status Active
Type Chip On Board (COB)
Color White, Warm
Configuration Round
Voltage - Forward (Vf) (Typ) 28.3V
Viewing Angle 120°
Current - Test 1.05A
Lumens/Watt @ Current - Test 80 lm/W
CCT (K) 1750K 4-Step MacAdam Ellipse
CRI (Color Rendering Index) 80
Current - Max 2.1A
Lens Type Flat
Temperature - Test 85°C
Flux @ Current/Temperature - Test 2384lm Typ
Light Emitting Surface (LES) 18.40mm Dia
Dimensions
Height 3.60mm
