150080SS75000

Würth Elektronik
RoHS
RoHS RoHS compliant
Package 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR 0805 SMD
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 1191
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height (Max) 0.80mm
Width 1.25mm
Length 2mm
Height 700μm

Technical

Wavelength - Dominant 630nm
Wavelength 630 nm
Lens Color Colorless
Wavelength - Peak 645nm
Lens Transparency Clear
Millicandela Rating 60mcd
Luminous Intensity 60 mcd
Forward Voltage 1.9V
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Forward Current 30mA
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 1.9V
Configuration Standard
Case Code (Imperial) 0805
Case Code (Metric) 2012
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 2.00mm Lx1.25mm W
Series WL-SMCW
Packaging Cut Tape (CT)

Physical

Supplier Device Package 0805
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
