CMDA5BR7D1S
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED 0805 SMD
PDF
/
Inventory: 9635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2012
Size / Dimension 2.00mm Lx1.25mm W
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Red
Power Rating 52mW
Packing Method TAPE AND REEL 7"
Number of Functions 1
Depth 1.25mm
Case Code (Metric) 2012
Case Code (Imperial) 0805
Number of Elements 1
Configuration Standard
Power Dissipation 52mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 170°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.40mmx1.25mm
Luminous Intensity 10 mcd
Millicandela Rating 10mcd
Lens Transparency Diffused
Wavelength - Peak 630nm
Lens Color Clear
Reverse Voltage 5V
Reverse Voltage (DC) 5V
Dimensions
Height 800μm
Compliance
RoHS Status ROHS3 Compliant
