CMD15-21UBC/TR8
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED BLUE CLEAR 1206 SMD
PDF
/
Buying Options
Total Price: USD $3.1
Unit Price: USD $3.0976
≥1 USD $3.0976
≥10 USD $2.1912
≥100 USD $1.837
Inventory: 5973
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 1.1mm
Technical
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 430nm
Lens Transparency Clear
Millicandela Rating 45mcd
Luminous Intensity 45 mcd
Lens Size 2.00mmx1.50mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140 °
Voltage - Forward (Vf) (Typ) 4.9V
Power Dissipation 105mW
Voltage 2.2V
Configuration Standard
Number of Elements 1
Case Code (Imperial) 1206
Case Code (Metric) 3216
Depth 1.5mm
Number of Functions 1
Packing Method TAPE AND REEL
Color Blue
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx1.50mm W
Published 2012
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 19 Weeks
