VLDS1535R-08 image
Favorite
VLDS1535R-08 image
Favorite
RoHS
RoHS RoHS compliant
Package 2-SMD, Z-Bend
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR 2SMD BOTTOM ENTRY
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.34144
≥100 USD $0.19624
Inventory: 2291
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mounting Type Surface Mount, Bottom Entry
Package / Case 2-SMD, Z-Bend
Supplier Device Package 2-SMD

Technical

Packaging Tape & Reel (TR)
Published 2017
Series VLD.1535
Size / Dimension 2.30mm Lx2.30mm W
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Color Red
Configuration Independent
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 44°
Current - Test 50mA
Lens Style Round with Domed Top
Lens Size 1.80mm Dia
Millicandela Rating 5000mcd
Lens Transparency Clear
Wavelength - Peak 639nm
Lens Color Colorless
Wavelength - Dominant 630nm

Dimensions

Height (Max) 2.75mm

Compliance

RoHS Status ROHS3 Compliant
