TLHF5400
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Orange Tint Diffused
PDF
/
Inventory: 4116
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height 8.7mm
Diameter 5mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 605nm
Wavelength - Peak 610nm
Lens Transparency Diffused
Luminous Intensity 160 mcd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Current - Test 10mA
Forward Current 20mA
Viewing Angle 60°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Base Part Number TLH5400
Subcategory Visible LEDs
Color Orange
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver (Sn/Ag)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Published 2008
Packaging Bulk
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
