OVSARGB3R8
RoHS
/
Package 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB CLEAR 4PLCC SMD
PDF
/
Inventory: 5670
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height (Max) 2.10mm
Width 2.8mm
Length 3.2mm
Height 2.1mm
Technical
Wavelength - Dominant 619nm Red 530nm Green 470nm Blue
Wavelength 469 nm
Lens Color Colorless
Wavelength - Peak 620nm Red 520nm Green 465nm Blue
Lens Transparency Clear
Millicandela Rating 300mcd Red, 450mcd Green, 110mcd Blue
Luminous Intensity 450 mcd
Forward Voltage 3.6V
Lens Style Round with Flat Top
Current - Test 20mA Red 20mA Green 20mA Blue
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.3V Red 3.6V Green 3.6V Blue
Configuration Common Anode
Voltage - Rated DC 3.6V
Color Red, Green, Blue (RGB)
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Part Status Obsolete
Size / Dimension 3.20mm Lx2.80mm W
Published 2005
Packaging Tape & Reel (TR)
Physical
Supplier Device Package 4-PLCC
Number of Pins 4
Package / Case 4-PLCC
Mounting Type Surface Mount
Mount Surface Mount
