OVS5MABCR4 image
Favorite
OVS5MABCR4 image
Favorite
RoHS
RoHS RoHS compliant
Package 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description LED AMBER CLEAR 2SMD
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.3256
≥100 USD $0.3168
Inventory: 445
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Height (Max) 1.40mm
Length 3.5mm

Technical

Wavelength - Dominant 615nm
Wavelength 615 nm
Reverse Voltage 12V
Lens Color Colorless
Lens Transparency Clear
Illumination Color Orange
Millicandela Rating 7150mcd
Luminous Intensity 4.5 cd
Forward Voltage 2.2V
Lens Size 2.60mm Dia
Lens Style Round with Flat Top
Current - Test 140mA
Forward Current 200mA
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 750mW
Max Current Rating 200mA
Configuration Standard
Number of Elements 1
Depth 3.5mm
Max Power Dissipation 330mW
Power Rating 500mW
Color Amber
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Size / Dimension 3.50mm Lx3.50mm W
Published 2009
Packaging Tape & Reel (TR)

Physical

Supplier Device Package 2-SMD
Number of Pins 2
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
