XZURMG56W
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 3SMD R/A
PDF
/
Inventory: 4708
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Wavelength - Peak 565nm Green 627nm Red
Lens Color Colorless
Forward Current-Max 0.03A
Wavelength - Dominant 568nm Green 617nm Red
Lens Transparency Clear
Millicandela Rating 14mcd Green, 7mcd Red
Luminous Intensity 7 mcd
Lens Size 2.00mmx1.00mm
Lens Style Rectangle with Domed Top
Current - Test 20mA Green 20mA Red
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2.2V Green 2V Red
Configuration Common Anode
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 3.5mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
HTS Code 8541.40.20.00
Color Green, Red
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.00mm Lx2.00mm W
Published 2008
Packaging Tape & Reel (TR)
Dimensions
Height 1mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Shape RECTANGULAR
Package / Case 3-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
