XZMECBDDG45S
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
Round with Flat Top 1 TRIPLE COLOR LED Red Green Blue (RGB) LED Indication Discrete 2V Red 3.3V Green 3.3V Blue 20mA Red 20mA Green 20mA Blue 218mcd Red 497mcd Green 98mcd Blue 120°
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.063104
≥1 USD $1.063104
≥10 USD $1.00293
≥100 USD $0.946162
≥500 USD $0.892604
≥1000 USD $0.842085
Inventory: 9291
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 2.1mm
Technical
Wavelength - Dominant 621nm Red 525nm Green 460nm Blue
Forward Current-Max 0.03A
Lens Color Colorless
Wavelength - Peak 630nm Red 515nm Green 465nm Blue
Lens Transparency Clear
Millicandela Rating 218mcd Red, 497mcd Green, 98mcd Blue
Luminous Intensity 98 mcd
Lens Size 2.40mm Dia
Lens Style Round with Flat Top
Current - Test 20mA Red 20mA Green 20mA Blue
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2V Red 3.3V Green 3.3V Blue
Configuration Common Anode
Operating Temperature (Max) 85°C
Number of Functions 1
Packing Method TR, 7 INCH
Color Red, Green, Blue (RGB)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx2.80mm W
Published 2014
Packaging Cut Tape (CT)
Physical
Number of Pins 4
Package / Case 4-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
