XZM2CRKM2DGFBB45SCCB
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB CLEAR 4PLCC SMD
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.5852
≥100 USD $0.383328
≥500 USD $0.302632
Inventory: 102857
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 2.1mm
Technical
Ambient Temperature Range High 85°C
Wavelength - Dominant 625nm Red 525nm Green 470nm Blue
Forward Current-Max 0.03A
Lens Color Colorless
Wavelength - Peak 640nm Red 520nm Green 465nm Blue
Lens Transparency Clear
Millicandela Rating 497mcd Red, 1590mcd Green, 327mcd Blue
Luminous Intensity 327 mcd
Lens Size 2.40mm Dia
Lens Style Round with Flat Top
Current - Test 20mA Red 20mA Green 20mA Blue
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.2V Red 3.2V Green 3.3V Blue
Configuration Common Cathode
Number of Functions 1
Packing Method TR, 7 INCH
Color Red, Green, Blue (RGB)
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 3.20mm Lx2.80mm W
Published 2014
Packaging Cut Tape (CT)
Physical
Manufacturer Package Identifier XZM2CRKM2DGFBB45SCCB
Number of Pins 4
Package / Case 4-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
