XZDGK45WT
RoHS
RoHS compliant
RoHS compliantPackage 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR 2PLCC
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
≥10 USD $0.33792
≥100 USD $0.194216
≥500 USD $0.151985
Inventory: 1236
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 2.10mm
Technical
Wavelength - Dominant 525nm
Overall Height 1.8mm
Forward Current-Max 0.03A
Lens Color Colorless
Wavelength - Peak 515nm
Lens Transparency Clear
Millicandela Rating 497mcd
Luminous Intensity 497.0 mcd
Lens Size 2.40mm Dia
Lens Style Round with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 3.3V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 3.1mm
Number of Functions 1
Packing Method TR, 7 INCH
Color Green
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx2.80mm W
Published 2016
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 2-PLCC
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
